Описание
| Drawing | Size(mm) | d(mm) | d1(mm) | L(mm) | L1(mm) | B1(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|
 |
13 | 13 | 16 | 152 | 31 | 31 | 640 | 1,000 |
|
16 | 16 | 19 | 188 | 41 | 38 | 1,180 | 1,600 |
|
19 | 21 | 22 | 229 | 50 | 42 | 2,190 | 1,950 |
Swivel with Thick Pin
*Materials: Body: SCS13 (equivalent to SUS304)
Pin & Nut: SUS304
*Do not use under conditions of constant rotation.
