Swivel

*Materials: Body SCS13 (equivalent to SUS304)
Pin & Nut: SUS304
* Not for use under conditions of constant rotation.

Категория: Swivels

Описание

Size(mm)	d(mm)	L(mm)	L1(mm)	B1(mm)	Unit Weight(g)	Work Load Limit (kg)
4	4	51	11	11	22	50
5	5	60	14	13	39	80
6	6	71	17	15	60	130
8	8	94	20	20	147	250
9	9	102	22	22	200	290
10	10	118	27	24	285	300
12	12	132	27	25	420	600
13	13	152	35	31	605	600
16	16	188	45	38	1,100	1,000
19	21	229	52	42	2,250	1,600
22	23.5	248	52	47	3,130	2,100
25	26	291	66	63	4,820	2,600
28	29	340	76	70	6,600	3,200
32	33	389	87	80	9,500	4,200
