| Drawing | Size | L(mm) | B(mm) | P(mm) | P1(mm) | P2(mm) | D(mm) | H(mm) | H1(mm) | H2(mm) | t(mm) | Thread dia.(mm) | Hole dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
W-1″ 1/4 | 200 | 100 | 100 | 180 | 80 | 47 | 48 | 19 | 26 | 3 | 1″1/4 | 10 | 710 |
|
W-1″ 1/2 | 220 | 110 | 110 | 200 | 90 | 53 | 48 | 21 | 24 | 3 | 1″1/2 | 10 | 860 |
|
W-2″ | 260 | 130 | 130 | 240 | 110 | 66 | 56 | 23 | 30 | 3 | 2″ | 10 | 1,320 |
