| Drawing | Size (Sheave dia.)(mm) | Sheave Qty | Max dia of rope(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | D1(mm) | B(mm) | B1(mm) | B2(mm) | t(mm) | t1(mm) | Hex. Wrench dia.(mm) | Bearing nom. No. | Unit Weight(kg) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
125 | 1 | 20 | 20 | 325 | 42 | 161 | 111 | 133 | 32 | 30 | 30 | 68 | 6･8･10 | 6308 | 6.2 | 3 |
|
150 | 1 | 20 | 23 | 370 | 50 | 180 | 132 | 159 | 38 | 30 | 33 | 75 | 8･14 | 6310 | 9.4 | 5 |
|
175 | 1 | 24 | 26 | 427 | 57 | 208 | 155 | 185 | 44 | 40 | 39 | 85 | 8･10･14 | 6312 | 14.4 | 6 |
Block
