*Material: Special stainless steel
Hook Bolt: SUS304
*»L2″ indicates the dimension at the maximum extended length.
The main body is made of «special stainless steel» excellent in corrosion resistance and strength.
In addition, the screw hole and the tool hole which stress is concentrated and need more strength are made thicker.
Can be turned by various tools such as driver or monkey wrench.
Suitable for connecting with the turnbuckle body, as well as to be used where visibility and beauty are required.
| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | D(mm) | S(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
12 | 200 | 303 | 465 | 329 | 24.5 | 17 | W1/2 | 600 | 375 |
|
16 | 250 | 368 | 565 | 400 | 27.4 | 22 | W5/8 | 1,040 | 600 |
|
19 | 300 | 438 | 678 | 478 | 33.5 | 25 | W3/4 | 1,720 | 800 |
|
22 | 325 | 489 | 739 | 535 | 39.4 | 31 | W7/8 | 2,650 | 1,000 |
|
25 | 350 | 536 | 796 | 590 | 42.7 | 36 | W1 | 3,690 | 1,350 |
