| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | D1(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 70 | 105 | 143 | 114 | 13 | 10 | W3/16 | 48 | 80 |
|
6 | 88 | 126 | 171 | 137 | 17 | 10 | W1/4 | 90 | 125 |
|
8 | 125 | 175 | 248 | 189 | 21 | 14 | W5/16 | 195 | 285 |
|
9 | 155 | 217 | 272 | 233 | 24 | 19 | W3/8 | 350 | 410 |
|
12 | 212 | 318 | 453 | 340 | 34 | 26 | W1/2 | 790 | 600 |
|
16 | 250 | 375 | 533 | 403 | 42 | 25*40 | w5/8 | 1,480 | 900 |
Turnbuckles
