| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | D(mm) | D1(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 80 | 126 | 176 | 134 | 11 | 9 | M5 | 40 | 80 |
|
6 | 91 | 139 | 200 | 149 | 12.7 | 10 | M6 | 65 | 110 |
|
8 | 112 | 178 | 260 | 192 | 13.8 | 14 | M8 | 135 | 260 |
|
10 | 130 | 216 | 316 | 234 | 15.8 | 20 | M10 | 240 | 350 |
|
12 | 150 | 264 | 384 | 284 | 19 | 25 | M12 | 415 | 450 |
Turnbuckles
