| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | S(mm) | D(mm) | D1(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 80 | 124 | 180 | 140 | 8 | 11 | 12 | M5 | 60 | 80 |
|
6 | 5 | 91 | 132 | 200 | 150 | 8 | 12.7 | 12 | M6 | 80 | 110 |
|
8 | 6 | 112 | 162 | 240 | 182 | 10 | 13.8 | 13 | M8 | 140 | 260 |
|
10 | 8 | 120 | 177 | 270 | 203 | 11 | 15.8 | 16 | M10 | 220 | 350 |
|
12 | 12 | 150 | 212 | 327 | 241 | 14 | 19 | 19 | M12 | 450 | 450 |
Turnbuckles
