| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | S(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 69 | 112 | 174 | 124 | 14 | 9 | M5 | 45 | 50 |
|
6 | 89 | 141 | 206 | 155 | 18 | 9 | M6 | 83 | 75 |
|
8 | 119 | 186 | 276 | 203 | 22 | 11 | M8 | 170 | 125 |
|
10 | 151 | 227 | 342 | 245 | 24 | 12 | M10 | 288 | 175 |
|
12 | 201 | 297 | 452 | 320 | 31 | 14 | M12 | 563 | 275 |
Turnbuckles
