| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|
 |
6 | 88 | 35 | 223 | 158 | 17 | W1/4 | 58 | 125 |
|
8 | 125 | 40 | 302 | 205 | 21 | W5/16 | 128 | 285 |
|
9 | 155 | 45 | 368 | 245 | 25 | W3/8 | 264 | 410 |
|
12 | 212 | 50 | 484 | 312 | 34 | W1/2 | 609 | 600 |
|
16 | 250 | 60 | 572 | 370 | 42 | W5/8 | 780 | 900 |
|
19 | 300 | 75 | 692 | 450 | 50 | W3/4 | 1,570 | 1,070 |
|
22 | 325 | 90 | 755 | 505 | 60 | W7/8 | 3,054 | 2,100 |
|
25 | 350 | 100 | 806 | 550 | 70 | W1 | 4,615 | 2,700 |
Turnbuckles
