| Drawing | Size(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | S(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 88 | 158 | 212 | 169 | 17 | 6 | M6 | 90 | 75 |
|
8 | 125 | 203 | 289 | 217 | 21 | 6 | M8 | 195 | 125 |
|
10 | 155 | 248 | 357 | 265 | 25 | 8 | M10 | 350 | 175 |
|
12 | 212 | 337 | 514 | 357 | 34 | 13.5 | M12 | 380 | 275 |
Turnbuckles
