| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | B(mm) | Thread dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|
 |
80*24 | 10 | 80 | 30 | 30 | 24 | M8 | 110 |
|
100*24 | 10 | 100 | 45 | 45 | 24 | M8 | 115 |
|
130*24 | 10 | 130 | 80 | 65 | 24 | M8 | 125 |
|
100*30 | 10 | 100 | 50 | 40 | 30 | M8 | 140 |
|
80*40 | 10 | 80 | 25 | 25 | 40 | M8 | 130 |
|
110*52 | 10 | 110 | 65 | 45 | 52 | M10 | 170 |
|
150*48 | 12 | 150 | 75 | 65 | 48 | M10 | 260 |
U-Bolts
