Описание
| Drawing | Size(mm) | d(mm) | L1(mm) | B(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|
 |
9 | 8 | 50 | 36 | 20 | M8 | 120 | 220 |
|
12 | 12 | 60 | 56 | 24 | M12 | 290 | 350 |
Wide D-Shackle with Hex Head Bolt & Cotter Pin
*Material: SCS14 (equivalent to SUS316)
Pin: SUS316
Cotter pin&Nut: SUS304
