| Drawing | Dia of wire rope(mm) | r(mm) | d(mm) | P(mm) | H(mm) | H1(mm) | L(mm) | B(mm) | Clamping torque(Nm) | Qty(pcs.) | Space(cm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
4 | 2 | M4 | 10 | 10 | 22 | 19 | 11 | 2.2 | 3 | 5 | 8 |
|
5 | 2.5 | M5 | 11.5 | 12.5 | 25.5 | 22.5 | 13 | 3.0 | 3 | 5 | 15 |
|
6 | 3 | M6 | 14 | 15 | 32 | 26 | 13 | 4.4 | 3 | 5 | 25 |
|
8 | 4 | M8 | 17 | 19 | 42 | 32 | 17 | 10 | 4 | 5 | 52 |
Wire Clips, Wire Clips
