Wire Rope Clip (Single)/(Double)

*Material:SUS304
*Diameter of wire rope used may differ from the above mentioned sizes.
*The gaps between clips and the length of wire rope at the end of the clip should be at least six times longer than the rope diameter.

Категории: ,

Описание

Drawing Spec Dia.of wire rope (mm) Size(mm) L(mm) B(mm) Unit Weight(g)
Drawing Single 1.5 2 15 11 4
Drawing Single 2 3 17 14 5
Drawing Single 3 4 20 17.5 10
Drawing Single 4 5 25 19 14
Drawing Single 5 6 30 25 26
Drawing Single 6 8 38 31 49
Drawing Single 8 10 47.5 37.5 92
Drawing Double 1.5 2 30 11 9
Drawing Double 2 3 34 14 11
Drawing Double 3 4 40 17.5 21
Drawing Double 4 5 50 19 27
Drawing Double 5 6 60 25 52
Drawing Double 6 8 75 30.5 100
Drawing Double 8 10 95 39 184
