| Drawing | Size(mm) | L(mm) | B(mm) | P(mm) | H(mm) | t(mm) | D(mm) | D1(mm) | Hole dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
125 | 80 | 125 | 55 | 125 | 6 | 42.7 | 16 | 10 | 820 |
|
150 | 100 | 150 | 70 | 150 | 6 | 48.6 | 19 | 11 | 1,300 |
|
200 | 140 | 200 | 110 | 200 | 9 | 60.5 | 25 | 11 | 3,300 |
|
250 | 190 | 250 | 150 | 250 | 10 | 76.3 | 28 | 13 | 5,800 |
|
300 | 200 | 300 | 160 | 300 | 12 | 89.1 | 32 | 13 | 8,500 |
Mooring Fittings
