| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | D(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|
 |
3 | 3 | 43 | 31 | 25 | 10 | 10 |
|
4 | 4 | 43 | 31 | 30 | 20 | 15 |
|
5 | 5 | 50 | 35 | 35 | 30 | 20 |
|
6 | 6 | 54 | 35 | 40 | 50 | 25 |
|
8 | 8 | 63 | 42 | 45 | 92 | 30 |
