| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B1(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|
 |
10 | 10 | 130 | 27 | 41 | 110 | 32 | 410 | 300 |
|
13 | 13 | 160 | 33 | 49 | 134 | 38 | 800 | 600 |
|
16 | 16 | 182 | 35 | 53 | 150 | 42 | 1,300 | 1,000 |
|
19 | 19 | 222 | 48 | 67 | 184 | 45 | 1,800 | 1,600 |
|
22 | 22 | 256 | 58 | 78 | 212 | 50 | 2,600 | 2,100 |
|
25 | 25 | 280 | 61 | 84 | 230 | 55 | 3,600 | 2,600 |
