| Drawing | Nominal Dia. (d)(mm) | Inside Dia. D1(mm) | D2(mm) | L(mm) | L1(mm) | L2(mm) | Work Load Limit (t) | Unit Weight(kg) |
|---|---|---|---|---|---|---|---|---|
 |
16 | 120 | 36 | 250 | 170 | 80 | 0.45 | 1.3 |
|
19 | 130 | 42 | 300 | 170 | 130 | 0.7 | 2.3 |
|
22 | 150 | 50 | 350 | 170 | 180 | 1 | 3.6 |
|
25 | 175 | 55 | 400 | 170 | 230 | 1.25 | 5.3 |
|
25 | 200 | 55 | 400 | 170 | 230 | 1.10 | 5.6 |
|
28 | 200 | 100 | 450 | 170 | 280 | 1.5 | 7.6 |
|
32 | 200 | 100 | 450 | 170 | 280 | 2 | 10.1 |
Mooring Fittings
